Bosch Rexroth A11VO A11VLO axial piston pumps for the Liebherr Mining Excavator 10001530 10037830 10036356 10292793 10450744 11824786 512293414

The A11VO and A11VLO are both variable-displacement axial piston pumps from Rexroth's A11V product line, built primarily for **open-circuit** applications — meaning they draw fluid from a reservoir/tank rather than recirculating it directly from the motor return line, as closed-circuit pumps do.

A11VO: The Foundation Model

The A11VO is the standard swashplate-design pump in this series. It's built for high-pressure, high-power hydrostatic drives and typically serves as the main working pump on excavators — powering boom, stick, bucket, and swing circuits through the machine's main control valve bank.

Key characteristics:

Nominal pressure typically up to 350 bar, with peak pressure capability higher still

Displacement sizes scaling from smaller units up through very large frame sizes (the mining-class machines use the largest displacements in the range)

Multiple control options: pressure cut-off, load-sensing, power control (electrohydraulic or hydraulic), and combinations of these

Through-drive capability, allowing several pumps to be tandemor triple-mounted off a single engine or transmission output — essential on excavators where one diesel engine drives multiple independent hydraulic circuits

A11VLO: The Long-Stroke Variant

The A11VLO is closely related but uses a longer-stroke design, which generally allows for a more favorable pressure-flow characteristic and different control dynamics at the extremes of the swashplate angle. Liebherr and other OEMs select A11VLO over standard A11VO in applications where control precision, response time, or specific packaging constraints make the long-stroke geometry preferable — for instance, in circuits demanding very fine metering during precision digging or fine-grading passes.

In practice, on a mining excavator, you'll often find A11VO and A11VLO units mounted together in a tandem or triple-pump group, each dedicated to a different function group (e.g., one pump for boom/swing, another for stick/bucket, a third for auxiliary or cooling fan drive circuits).

Why Liebherr Uses A11VO/A11VLO Pumps in Mining Excavators

Liebherr's mining excavator line — machines in the R 9000 class used for overburden removal and hard-rock loading — runs some of the largest hydraulic systems in the earthmoving world. Choosing a pump family isn't a casual decision; it comes down to a few hard requirements.

1. Power Density at Extreme Duty Cycles

Mining excavators run near-continuous digging cycles, often 20+ hours a day, in high-ambient-temperature environments (open-pit mines in Australia, Chile, or the American West, for example). The A11VO/A11VLO series is built to sustain high pressure and high flow continuously, not just in bursts, which matters enormously when duty cycles rarely give the hydraulic system a chance to cool down or idle.

2. Precise, Programmable Control

Modern Liebherr excavators use electrohydraulic control systems (Liebherr's Litronic control architecture is a good example) that talk directly to the pump's displacement controller. The A11VO/A11VLO's electrohydraulic power control lets the machine's control system continuously adjust pump swashplate angle based on engine load, joystick input, and system pressure — matching hydraulic output to exactly what the operator is asking for, which is how these machines achieve both raw digging force and fuel efficiency in the same package.

3. Modular, Multi-Pump Architecture

Because A11V-series pumps support through-drive tandem mounting, Liebherr can gang multiple pumps off a single engine flywheel housing, each independently controlled but mechanically synchronized in speed. This is exactly the architecture mining excavators need: independent flow for boom/arm, independent flow for swing, and dedicated flow for cooling and auxiliary systems — all from one power source.

4. Proven Reliability in Harsh Environments

Mine sites are dusty, vibration-heavy, and thermally brutal. The A11VO/A11VLO's robust cylinder block and bearing design, combined with Rexroth's decades of field data across construction and mining OEMs, gives Liebherr a pump platform with a known failure-mode profile — which matters as much for planned maintenance intervals as it does for raw uptime.

For more brands and equipment models, please visit https://www.baolilaihydraulic.com/brand/

Q1: How do I know if my A11VO/A11VLO pump needs service?

A1: Watch case drain flow, output pressure/flow performance versus spec, unusual noise or cavitation sounds, and displacement response time. A qualified hydraulic technician should perform flow and pressure testing against Rexroth's published specifications rather than relying on symptoms alone.

Q2: Why do mining excavators use multiple pumps instead of one large pump?

A2: Splitting hydraulic power across multiple pumps (often three or more) allows independent control of different function groups — boom/swing versus stick/bucket, for example — so one function doesn't starve another of flow. It also improves redundancy: a fault on one pump doesn't necessarily take down the entire machine.

Q3: What is the price and delivery time of the A11VO A11VLO hydraulic pump for the Liebherr Mining Excavator?

A3: The specific price and delivery time will depend on the equipment model or specific product model you provide.

Q4: How to purchase an A11VO A11VLO hydraulic pump for the Liebherr Mining Excavator?

A4: You can visit https://www.baolilaihydraulic.com/contact/ to contact us and purchase our products through various methods.
