The Parker PV080 is a robust axial piston variable displacement hydraulic pump designed for open-circuit systems. It features a swashplate design that enables smooth and efficient variation of flow output, proportional to the drive shaft speed and the swashplate angle. This pump is engineered for demanding mobile and industrial applications, offering high power density and reliable performance under continuous high-pressure operation, typically up to 350 bar (approx. 5075 psi).
Key characteristics include its variable displacement mechanism, which allows for flow-on-demand, significantly improving system efficiency and reducing heat generation. The PV080 is known for its quiet operation, long service life, and excellent contamination tolerance. It commonly integrates with various controls, such as pressure compensators or load-sensing controls, to optimize performance for specific hydraulic system requirements. Its compact design and mounting versatility make it a preferred choice for construction machinery, material handling equipment, and other heavy-duty applications where precise hydraulic power and durability are essential.
Specifications
| PV016 | PV020 | PV023 | PV028 | PV032 | PV040 | PV046 | PV063 | PV080 | PV092 | PV140 | PV180 | PV270 | PV360 | ||
| Frame size | 1 | 1 | 1 | 1 | 2 | 2 | 2 | 3 | 3 | 3 | 4 | 4 | 5 | 5 | |
| Max. Displacement | [cm³/rev.] | 16 | 20 | 23 | 28 | 32 | 40 | 46 | 63 | 80 | 92 | 140 | 180 | 270 | 360 |
| Output flow at 1500 rpm | [l/min] | 24 | 30 | 34.5 | 42 | 48 | 60 | 69 | 94.5 | 120 | 138 | 270 | 405 | 405 | 540 |
| Nominal pressure pN | [bar] | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 |
| Max. pressure pmax at 20% working cycle | [bar] | 420 | 420 | 420 | 420 | 420 | 420 | 420 | 420 | 420 | 420 | 420 | 420 | 420 | 420 |
| Case drain pressure, continuous | [bar] | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.55 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 |
| Case drain pressure, max. peak | [bar] | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 |
| Min. Inlet pressure, abs. | [bar] | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 |
| Max. Inlet pressure | [bar] | 16 | 16 | 16 | 16 | 16 | 16 | 16 | 16 | 16 | 16 | 16 | 16 | 16 | 16 |
| Input power at 1500 rpm and 350 bar | [kW] | 15.5 | 19.5 | 22.5 | 27.5 | 31 | 39 | 45 | 61.5 | 78 | 89.5 | 136 | 175 | 263 | 350 |
| Max speed at 1 bar, abs, inlet pressure | [rpm] | 3000 | 3000 | 3000 | 3000 | 2800 | 2800 | 2800 | 2800 | 2500 | 2300 | 2400 | 2200 | 1800 | 1750 |
| Moment of inertia | [kgm²] | 0.0017 | 0.0017 | 0.0017 | 0.0017 | 0.0043 | 0.0043 | 0.0043 | 0.018 | 0.018 | 0.018 | 0.030 | 0.030 | 0.098 | 0.103 |
| Weight | [kg] | 19 | 19 | 19 | 19 | 30 | 30 | 30 | 59 | 59 | 59 | 90 | 90 | 172 | 180 |
Selection Table
| PV080 axial piston hydraulic pump |
| Model Code |
| PV080L1D1T1NMRC |
| PV080L1D3T1NWLC |
| PV080L1E1CDNMMC |
| PV080L1E1CDNMMC4747 |
| PV080L1E1T1NMF1 |
| PV080L1E1T1NMMC |
| PV080L1E3T1NMF1 |
| PV080L1E3T1NMFC |
| PV080L1E3T1NMFC4747 |
| PV080L1E3T1NMMC |
| PV080L1E3T1NMMC4747 |
| PV080L1K1T1N001 |
| PV080L1K1T1N100 |
| PV080L1K1T1NFFC |
| PV080L1K1T1NFHS |
| PV080L1K1T1NFWS |
| PV080L1K1T1NMF1 |
| PV080L1K1T1NMFC |
| PV080L1K1T1NMLC |
| PV080L1K1T1NMM1 |
| PV080L1K1T1NMMC |
| PV080L1K1T1NMMC4747 |
| PV080L1K1T1NMMK |
| PV080L1K1T1NMRK |
| PV080L1L1KJNMFC |
| PV080L1L1T1NMFC |
| PV080L1L1T1NMM1 |
| PV080L1L1T1NMMC |
| PV080L1L1T1NTLC |
| PV080L1L1T1WUPM |
| PV080R1D1T1NMMC |
| PV080R1D1T1NUPR |
| PV080R1D1T1VFWS |
| PV080R1D1T1VMMC |
| PV080R1D3AYNMM1 |
| PV080R1D3B1NUPR |
| PV080R1D3C1NGLA |
| PV080R1D3C1NKLA |
| PV080R1D3C1NKLW |
| PV080R1D3C1NSCC |
| PV080R1D3CDNMMC |
| PV080R1D3CDNMMC4747 |
| PV080R1D3CDNMR1 |
| PV080R1D3CDNMRK |
| PV080R1D3DFNUPP |
| PV080R1D3T1NFDS |
| PV080R1D3T1NFHS |
| PV080R1D3T1NFWS |
| PV080R1D3T1NHLC |
| PV080R1D3T1NKLC |
| PV080R1D3T1NMCC |
| PV080R1D3T1NMF1 |
| PV080R1D3T1NMLC |
| PV080R1D3T1NMMC |
| PV080R1D3T1NMMC4747 |
| PV080R1D3T1NMMW |
| PV080R1D3T1NMRC |
| PV080R1D3T1NMRC4747 |
| PV080R1D3T1NTCC |
| PV080R1D3T1NULC |
| PV080R1D3T1NULZ |
| PV080R1D3T1NUPF |
| PV080R1D3T1NUPK |
| PV080R1D3T1NUPM |
| PV080R1D3T1NUPP |
| PV080R1D3T1NUPR |
| PV080R1D3T1VMFC |
| PV080R1D3T1WMRC |
| PV080R1D3T1WMRC4747 |
| PV080R1D7T1VMFC |
| PV080R1E1AYNMFC |
| PV080R1E1AYNUPR |
| PV080R1E1BBNMT1 |
| PV080R1E1DFNMFC |
| PV080R1E1T1VTCC |
| PV080R1E3AYNMFC |
| PV080R1E3AYNMFC4747 |
| PV080R1E3T1NUPM |
| PV080R1E4AYNSCC |
| PV080R1E8T1NMMC |
| PV080R1K1A1NFR1 |
| PV080R1K1A1NFWS |
| PV080R1K1A1NHLC |
| PV080R1K1A1NMMC |
| PV080R1K1AYNFRC |
| PV080R1K1AYNMLC |
| PV080R1K1AYNMRC |
| PV080R1K1AYNMRC4747 |
| PV080R1K1AYNMRZ |
| PV080R1K1AYNUPM |
| PV080R1K1AYNUPR |
| PV080R1K1B1NHCC |
| PV080R1K1B1NHCC4747 |
| PV080R1K1B1NSLB |
| PV080R1K1BBNGCZ |
| PV080R1K1BBNMCZ |
| PV080R1K1BBNMLK |
| PV080R1K1BBNMMC |
| PV080R1K1BBNMMC4747 |
| PV080R1K1JHNMMC |
| PV080R1K1JHNMMW |
| PV080R1K1JHNMR1 |
| PV080R1K1KJNMMC |
| PV080R1K1KJNSLW |
| PV080R1K1KJNSLW4747 |
| PV080R1K1LKNMMC |
| PV080R1K1LKNMRC |
| PV080R1K1S1NFWS |
| PV080R1K1T1BMFC |
| PV080R1K1T1N001 |
| PV080R1K1T1N0014747 |
| PV080R1K1T1N100 |
| PV080R1K1T1N1004747 |
| PV080R1K1T1NFDS |
| PV080R1K1T1NFDV |
| PV080R1K1T1NFF1 |
| PV080R1K1T1NFFC |
| PV080R1K1T1NFFp |
| PV080R1K1T1NFHS |
| PV080R1K1T1NFPV |
| PV080R1K1T1NFR1 |
| PV080R1K1T1NFR2 |
| PV080R1K1T1NFRC |
| PV080R1K1T1NFRD |
| PV080R1K1T1NFRL |
| PV080R1K1T1NFRP |
| PV080R1K1T1NFRZ |
| PV080R1K1T1NFT1 |
| PV080R1K1T1NFWS |
| PV080R1K1T1NGC1 |
| PV080R1K1T1NGC14747 |
| PV080R1K1T1NGCC |
| PV080R1K1T1NGCK |
| PV080R1K1T1NGCZ |
| PV080R1K1T1NGL1 |
| PV080R1K1T1NGLA |
| PV080R1K1T1NGLC |
| PV080R1K1T1NGLC4747 |
| PV080R1K1T1NHCB |
| PV080R1K1T1NHCC |
| PV080R1K1T1NHCC4747 |
| PV080R1K1T1NHCD |
| PV080R1K1T1NHL1 |
| PV080R1K1T1NHLC |
| PV080R1K1T1NHLC4747 |
| PV080R1K1T1NHLK |
| PV080R1K1T1NHLW |
| PV080R1K1T1NHLZ |
| PV080R1K1T1NKCC |
| PV080R1K1T1NKL1 |
| PV080R1K1T1NKLC |
| PV080R1K1T1NKLC4747 |
| PV080R1K1T1NMC1 |
| PV080R1K1T1NMCC |
| PV080R1K1T1NMCC4747 |
| PV080R1K1T1NMF1 |
| PV080R1K1T1NMF14747 |
| PV080R1K1T1NMFB |
| PV080R1K1T1NMFC |
| PV080R1K1T1NMFC4747 |
| PV080R1K1T1NMFW |
| PV080R1K1T1NMFZ |
| PV080R1K1T1NML1 |
| PV080R1K1T1NML14747 |
| PV080R1K1T1NMLB |
| PV080R1K1T1NMLB4747 |
| PV080R1K1T1NMLC |
| PV080R1K1T1NMLC4747 |
| PV080R1K1T1NMLK |
| PV080R1K1T1NMLW |
| PV080R1K1T1NMLZ |
| PV080R1K1T1NMM1 |
| PV080R1K1T1NMM14747 |
| PV080R1K1T1NMMC |
| PV080R1K1T1NMMC4747 |
| PV080R1K1T1NMMK |
| PV080R1K1T1NMMW |
| PV080R1K1T1NMMW4747 |
| PV080R1K1T1NMMZ |
| PV080R1K1T1NMMZ4747 |
| PV080R1K1T1NMR1 |
| PV080R1K1T1NMR14747 |
| PV080R1K1T1NMRC |
| PV080R1K1T1NMRC4747 |
| PV080R1K1T1NMRK |
| PV080R1K1T1NMRW |
| PV080R1K1T1NMRW4747 |
| PV080R1K1T1NMRZ |
| PV080R1K1T1NMRZ4747 |
| PV080R1K1T1NMT1 |
| PV080R1K1T1NMTK |
| PV080R1K1T1NMTP |
| PV080R1K1T1NSC1 |
| PV080R1K1T1NSCB |
| PV080R1K1T1NSCC |
| PV080R1K1T1NSCC4747 |
| PV080R1K1T1NSCK |
| PV080R1K1T1NSCK4747 |
| PV080R1K1T1NSCW |
| PV080R1K1T1NSCW4747 |
| PV080R1K1T1NSL1 |
| PV080R1K1T1NSL14747 |
| PV080R1K1T1NSLA |
| PV080R1K1T1NSLB |
| PV080R1K1T1NSLB4747 |
| PV080R1K1T1NSLC |
| PV080R1K1T1NSLC4747 |
| PV080R1K1T1NSLD |
| PV080R1K1T1NSLK |
| PV080R1K1T1NSLK4747 |
| PV080R1K1T1NSLW |
| PV080R1K1T1NSLZ |
| PV080R1K1T1NTC1 |
| PV080R1K1T1NTCC |
| PV080R1K1T1NTCC4747 |
| PV080R1K1T1NTL1 |
| PV080R1K1T1NTLC |
| PV080R1K1T1NTLD |
| PV080R1K1T1NTLW |
| PV080R1K1T1NUCC |
| PV080R1K1T1NUCC4747 |
| PV080R1K1T1NUCK |
| PV080R1K1T1NUDK |
| PV080R1K1T1NUDM |
| PV080R1K1T1NUDR |
| PV080R1K1T1NUL1 |
| PV080R1K1T1NULC |
| PV080R1K1T1NULW |
| PV080R1K1T1NULW4747 |
| PV080R1K1T1NUPE |
| PV080R1K1T1NUPG |
| PV080R1K1T1NUPR |
| PV080R1K1T1NWL1 |
| PV080R1K1T1NWLB |
| PV080R1K1T1NWLB4747 |
| PV080R1K1T1NWLC |
| PV080R1K1T1NWLC4747 |
| PV080R1K1T1VFDS |
| PV080R1K1T1VHLZ |
| PV080R1K1T1VKLC |
| PV080R1K1T1VMFC |
| PV080R1K1T1VMFC4747 |
| PV080R1K1T1VML1 |
| PV080R1K1T1VMM1 |
| PV080R1K1T1VMM14747 |
| PV080R1K1T1VMMC |
| PV080R1K1T1VMMC4747 |
| PV080R1K1T1VMMW |
| PV080R1K1T1VMMW4747 |
| PV080R1K1T1VMMZ |
| PV080R1K1T1VMMZ4747 |
| PV080R1K1T1VMRC |
| PV080R1K1T1WFDS |
| PV080R1K1T1WFR1 |
| PV080R1K1T1WHL1 |
| PV080R1K1T1WHLW |
| PV080R1K1T1WHLW4747 |
| PV080R1K1T1WKLW |
| PV080R1K1T1WMM1 |
| PV080R1K1T1WMM14747 |
| PV080R1K1T1WMMC |
| PV080R1K1T1WMMZ |
| PV080R1K1T1WMR1 |
| PV080R1K1T1WMRC |
| PV080R1K4T1N001 |
| PV080R1K4T1NFDV |
| PV080R1K4T1NFHS |
| PV080R1K4T1NFR1 |
| PV080R1K4T1NGL1 |
| PV080R1K4T1NHL1 |
| PV080R1K4T1NKL1 |
| PV080R1K4T1NKLC |
| PV080R1K4T1NMFB |
| PV080R1K4T1NMFC |
| PV080R1K4T1NMFC4747 |
| PV080R1K4T1NMM1 |
| PV080R1K4T1NMMC |
| PV080R1K4T1NMMC4747 |
| PV080R1K4T1NMMK |
| PV080R1K4T1NMMK4747 |
| PV080R1K4T1NMMW |
| PV080R1K4T1NMMZ |
| PV080R1K4T1NMMZ4747 |
| PV080R1K4T1NMR1 |
| PV080R1K4T1NMR14747 |
| PV080R1K4T1NMRC |
| PV080R1K4T1NMT2 |
| PV080R1K4T1NMTP |
| PV080R1K4T1NSC1 |
| PV080R1K4T1NSCC |
| PV080R1K4T1NSL1 |
| PV080R1K4T1NSLA |
| PV080R1K4T1NSLK |
| PV080R1K4T1NSLZ |
| PV080R1K4T1NSLZ4747 |
| PV080R1K4T1NTCC |
| PV080R1K4T1NTCC4747 |
| PV080R1K4T1NUPG |
| PV080R1K4T1NUPM |
| PV080R1K4T1NUPR |
| PV080R1K4T1VFHS |
| PV080R1K4T1VMM1 |
| PV080R1K4T1VMM14747 |
| PV080R1K4T1VMMC |
| PV080R1K4T1WMF1 |
| PV080R1K4T1WMF14747 |
| PV080R1K4T1WMM1 |
| PV080R1K4T1WMMC |
| PV080R1K4T1WMMC4747 |
| PV080R1K4T1WMMZ |
| PV080R1K8T1N001 |
| PV080R1K8T1NFPV |
| PV080R1K8T1NFWS |
| PV080R1K8T1NMMC |
| PV080R1K8T1VMMC |
| PV080R1L1B4NTCB |
| PV080R1L1BBNTCC |
| PV080R1L1J1NFFP |
| PV080R1L1KJNUCC |
| PV080R1L1L1NUPG |
| PV080R1L1L3NTCB |
| PV080R1L1LKNMMC |
| PV080R1L1LKNSCB |
| PV080R1L1LKNTCC |
| PV080R1L1LKNUCC |
| PV080R1L1LKWFPV |
| PV080R1L1T1MULC |
| PV080R1L1T1N001 |
| PV080R1L1T1N100 |
| PV080R1L1T1NFDS |
| PV080R1L1T1NFFC |
| PV080R1L1T1NFFP |
| PV080R1L1T1NFHS |
| PV080R1L1T1NFPV |
| PV080R1L1T1NFR1 |
| PV080R1L1T1NFR2 |
| PV080R1L1T1NFRC |
| PV080R1L1T1NFT1 |
| PV080R1L1T1NFWS |
| PV080R1L1T1NKLC |
| PV080R1L1T1NMF1 |
| PV080R1L1T1NMFC |
| PV080R1L1T1NMFC4747 |
| PV080R1L1T1NMLA |
| PV080R1L1T1NMLC |
| PV080R1L1T1NMLC4747 |
| PV080R1L1T1NMMC |
| PV080R1L1T1NMMC4747 |
| PV080R1L1T1NMMK |
| PV080R1L1T1NMMW |
| PV080R1L1T1NMMZ |
| PV080R1L1T1NMRC |
| PV080R1L1T1NMRC4747 |
| PV080R1L1T1NSCB |
| PV080R1L1T1NSCK |
| PV080R1L1T1NSL1 |
| PV080R1L1T1NTCC |
| PV080R1L1T1NUCC |
| PV080R1L1T1NUDR |
| PV080R1L1T1NULA |
| PV080R1L1T1NUPE |
| PV080R1L1T1NUPG |
| PV080R1L1T1NUPM |
| PV080R1L1T1NUPR |
| PV080R1L1T1NWLC |
| PV080R1L1T1NWLC4747 |
| PV080R1L1T1VFDS |
| PV080R1L1T1VMR1 |
| PV080R1L1T1VMR14747 |
| PV080R1L1T1WTCC |
| PV080R1L4BBNMMC |
| PV080R1L4CDNUPM |
| PV080R1L4T1NFWS |
| PV080R1L4T1NHCW |
| PV080R1L4T1NMFC |
| PV080R1L4T1NMMC |
| PV080R1L4T1NSCZ |
| PV080R1L4T1NUDM |
| PV080R1L4T1NUPG |
| PV080R1L4T1NUPM |
| PV080R1L4T1VFWS |
| PV080R1L4T1VMFK |
| PV080R1L4T1VMFK4747 |
| PV080R1L4T1VMM1 |
| PV080R1L4T1VMMC |
| PV080R1L4T1VSC1 |
| PV080R1L4T1VSC14747 |
| PV080R1L4T1WFWS |
| PV080R1L8L3NULC |
| PV080R1L8T1NFHS |
| PV080R2K1T1N001 |
| PV080R2K4LKN001 |
| PV080R2L1T1WMMW |
| PV080R2L4T1N001 |
| PV080R2L4T1WMMW |
| PV080R4D3T1VUDM |
| PV080R4D3T1VUDM4747 |
| PV080R4K1T1NFDV |
| PV080R4K1T1NFDV4747 |
| PV080R4K1T1NUDM |
| PV080R4K1T1NUDM4747 |
| PV080R4K1T1NUDR |
| PV080R4K1T1NUDR4747 |
| PV080R4K1T1VUDM |
| PV080R4K1T1VUDM4747 |
| PV080R4K4T1NUDR |
| PV080R4K4T1NUDR4747 |
| PV080R4L1T1NUDM |
| PV080R4L1T1NUDM4747 |
| PV080R4L1T1NUDR |
| PV080R4L1T1NUDR4747 |
| PV080R9E1BBNMT1 |
| PV080R9E1BBWMT2 |
| PV080R9E1DFWMT2 |
| PV080R9K1AYNGLB |
| PV080R9K1BBN100 |
| PV080R9K1T1NFWS |
| PV080R9K1T1NMFC |
| PV080R9K1T1NMM1 |
| PV080R9K1T1NMMC |
| PV080R9K1T1NMRC |
| PV080R9K1T1NSC1 |
| PV080R9K1T1NTCC |
| PV080R9K1T1NUCC |
| PV080R9L1T1NMFC |
| PV080R9L1T1NMMC |
Q1:In what type of hydraulic system is the Parker PV080 pump designed to operate?
A1: The Parker PV080 axial piston hydraulic pump is specifically designed for use in open-circuit hydraulic systems, commonly found in mobile and industrial machinery.
Q2: What is the primary function of a variable displacement hydraulic pump like the Parker PV080?
A2: The primary function of a variable displacement hydraulic pump is to provide flow-on-demand. It varies its output flow according to system needs, which improves overall efficiency and reduces unnecessary heat generation compared to a fixed-displacement hydraulic pump.
Q3:How to purchase a PV080 hydraulic pump?
A3:You can click on the right sidebar or the contact information in the top bar to contact us to purchase. You can do so via email, form, WeChat, WhatsApp, or other methods.
Q4:What is the price and delivery time of the PV080 hydraulic pump?
A4:The specific price and delivery time will be provided based on the specific model you provide.
