MPT025 Tandem variable hydraulic pump
SERIES : 40 seriers MPT
BRAND : For Sauer Danfoss
Model Size :MPT025
Displacement : 24.6X2cm3/rev
Speed : 500-4000rpm
Maximum Pressure : 345bar
Nominal Pressure : 210bar
Download PDF
- Product Details
- Product Model
- FAQ
The MPT025 is a tandem variable hydraulic pump designed for demanding mobile and industrial applications. Its core feature is the tandem configuration, which essentially combines two variable-displacement axial piston pump units onto a single drive shaft within one housing. This compact, space-saving design allows for the supply of two independent hydraulic circuits from a single power source, such as a diesel engine.
Key operational characteristics include variable displacement, typically controlled via a pressure-compensating mechanism or proportional solenoid. This enables the pump to automatically adjust its flow output to match system demand, maintaining a set pressure and improving overall system efficiency by reducing unnecessary flow and heat generation. The tandem design is particularly advantageous for systems requiring separate flows for different functions (e.g., steering and work hydraulics) with potentially different pressure settings. It offers flexibility, reduced complexity compared to two separate pumps, and contributes to better fuel economy and thermal management in the host machine. Common applications include construction equipment, agricultural machinery, and material handling vehicles.
Specifications
| Model | Unit | M25 PT | M35 PT | M44 PT | M46 PT |
| Pump configuration |
Tandem variable pump | ||||
| Displacement | cm3/rev [in3/rev] |
24.6x2 [1.50x2] |
35.0x2 [2.14x2] |
43.5x2 [2.65x2] |
46.0x2 [2.81x2] |
| Weight | kg[lb] | 24[56] | 45[99] | 45[99] | 59[131] |
| Mass moment of inertia | kg·m2[slug.ft2] | 0.0037[0.0028] | 0.0066[0.0048] | 0.0064[0.0047] | 0.0100[0.0073] |
| Case pressure | |||||
| Continuous | bar[psi] | 1.7[25] | |||
| Maximum | bar[psi] | 5.2[75] | |||
| Speed limits | |||||
| Rated@ max angle | min-1(rpm) | 4000 | 3600 | 3300 | 4000 |
| Maximim@ max angle | min-1(rpm) | 5000 | 4500 | 4100 | 4100 |
| Minimum | min-1(rpm) | 500 | 500 | 500 | 500 |
| System pressure | |||||
| Continuous | bar[psi] | 210[3000] | |||
| Maximum | bar[psi] | 345[5000] | |||
| Theoretical max flow at rated speed(per pump) | I/min [US gal/min] |
100 [26.0] |
126 [33.4] |
145 [38.3] |
184 [48.6] |
| Inlet pressure | |||||
| Continuous | bar absolute [in Hg vacuum] |
0.8[6.3] | |||
| Maximum | bar absolute [in Hg vacuum] |
0.7[9.2] | |||
Selection Table
| MPT025 Tandem variable hydraulic pump | ||
| Model No. | Model Code | Model Code |
| M91-25232 | MPT-025-C-C-7-A-G-NN-B-A-A-A-BBB-DL-A-FF-B-C-A-A-BBB-DL-A-FF-D-NNN-*** | MPT025CC7AGNNBAAABBBDLAFFBCAABBBDLAFFDNNN*** |
| M91-25203 | MPT-025-C-C-7-A-G-NN-B-A-A-A-BJJ-DL-A-FF-B-C-A-A-BJJ-DL-A-FF-D-NNN-*** | MPT025CC7AGNNBAAABJJDLAFFBCAABJJDLAFFDNNN*** |
| M91-25207 | MPT-025-C-C-7-A-G-NN-B-A-A-A-BJJ-DR-A-FF-B-C-A-A-BJJ-DR-A-FF-A-NNN-*** | MPT025CC7AGNNBAAABJJDRAFFBCAABJJDRAFFANNN*** |
| M91-25130 | MPT-025-C-C-L-A-E-NN-B-A-A-A-BFF-DL-A-FF-B-C-A-A-BFF-DL-A-FF-A-NNN-*** | MPT025CCLAENNBAAABFFDLAFFBCAABFFDLAFFANNN*** |
| M91-25125 | MPT-025-C-C-L-A-G-NN-B-A-A-A-BFF-DR-A-FF-B-C-A-A-BFF-DR-A-FF-A-NNN-*** | MPT025CCLAGNNBAAABFFDRAFFBCAABFFDRAFFANNN*** |
| M91-25122 | MPT-025-C-C-R-A-E-NN-B-A-A-A-BFF-DL-A-FF-B-C-A-A-BFF-DL-A-FF-A-NNN-*** | MPT025CCRAENNBAAABFFDLAFFBCAABFFDLAFFANNN*** |
| M91-25157 | MPT-025-C-C-R-A-E-NN-B-A-A-A-BFF-DR-A-FF-B-C-A-A-BFF-DR-A-FF-A-NNN-*** | MPT025CCRAENNBAAABFFDRAFFBCAABFFDRAFFANNN*** |
| M91-25156 | MPT-025-C-C-R-A-G-NN-B-A-A-A-BGG-DR-A-FF-B-A-A-A-BGG-DR-A-FF-A-NNN-*** | MPT025CCRAGNNBAAABGGDRAFFBAAABGGDRAFFANNN*** |
| M91-25158 | MPT-025-C-C-R-A-G-NN-B-A-A-A-BGG-DR-A-FF-B-C-A-A-BGG-DR-A-FF-A-NNN-*** | MPT025CCRAGNNBAAABGGDRAFFBCAABGGDRAFFANNN*** |
| M91-25170 | MPT-025-C-C-Y-A-E-NN-B-A-A-A-BGG-DL-A-FF-B-C-A-A-BGG-DL-A-FF-A-NNN-*** | MPT025CCYAENNBAAABGGDLAFFBCAABGGDLAFFANNN*** |
| M91-25187 | MPT-025-C-C-Y-A-G-NN-B-A-A-A-BDD-DR-A-FF-B-C-A-A-BDD-DL-A-FF-A-NNN-*** | MPT025CCYAGNNBAAABDDDRAFFBCAABDDDLAFFANNN*** |
| M91-25210 | MPT-025-C-C-Y-A-H-NN-B-A-A-A-BJJ-DL-A-FF-B-C-A-A-BJJ-DL-A-FF-D-NNN-*** | MPT025CCYAHNNBAAABJJDLAFFBCAABJJDLAFFDNNN*** |
| M91-25168 | MPT-025-C-K-L-A-E-NN-B-A-A-A-BDD-DR-A-FF-B-C-A-A-BDD-DR-A-FF-A-NNN-*** | MPT025CKLAENNBAAABDDDRAFFBCAABDDDRAFFANNN*** |
| M91-25167 | MPT-025-C-K-R-A-E-NN-B-A-A-A-BDD-DR-A-FF-B-C-A-A-BDD-DR-A-FF-A-NNN-*** | MPT025CKRAENNBAAABDDDRAFFBCAABDDDRAFFANNN*** |
| M91-25222 | MPT-025-C-K-R-A-E-NN-B-A-A-A-BFF-DR-A-FF-B-C-A-A-BFF-DR-A-FF-A-NNN-*** | MPT025CKRAENNBAAABFFDRAFFBCAABFFDRAFFANNN*** |
| M91-25201 | MPT-025-C-K-R-A-G-NN-B-A-A-A-BBB-DL-A-FF-B-C-A-A-BBB-DL-A-FF-A-NNN-*** | MPT025CKRAGNNBAAABBBDLAFFBCAABBBDLAFFANNN*** |
| M91-25240 | MPT-025-C-K-W-A-G-NN-B-A-A-A-BDD-DL-A-FF-B-C-A-A-BDD-DL-A-FF-A-NNN-*** | MPT025CKWAGNNBAAABDDDLAFFBCAABDDDLAFFANNN*** |
| M91-25192 | MPT-025-C-K-Y-A-E-NN-B-A-A-A-BDD-DL-A-FF-B-C-A-A-BDD-DR-A-FF-A-NNN-*** | MPT025CKYAENNBAAABDDDLAFFBCAABDDDRAFFANNN*** |
| M91-25213 | MPT-025-C-K-Y-A-G-NN-B-A-A-A-BDD-DL-A-FF-B-C-A-A-BDD-DR-A-FF-A-NNN-*** | MPT025CKYAGNNBAAABDDDLAFFBCAABDDDRAFFANNN*** |
| 83070663 | MPT-025-C-S-7-A-C-NN-B-A-A-A-BJJ-DL-A-FF-B-C-A-A-BJJ-DL-A-FF-A-NNN-*** | MPT025CS7ACNNBAAABJJDLAFFBCAABJJDLAFFANNN*** |
| M91-25224 | MPT-025-C-S-7-A-G-NN-B-A-A-A-BCC-DR-A-FF-B-C-A-A-BCC-DR-A-FF-A-NNN-*** | MPT025CS7AGNNBAAABCCDRAFFBCAABCCDRAFFANNN*** |
| M91-25197 | MPT-025-C-S-7-A-G-NN-B-A-A-A-BJJ-DL-A-FF-B-C-A-A-BJJ-DL-A-FF-A-NNN-*** | MPT025CS7AGNNBAAABJJDLAFFBCAABJJDLAFFANNN*** |
| M91-25214 | MPT-025-C-S-7-A-H-NN-B-A-A-A-BJJ-DR-A-FF-B-C-A-A-BJJ-DR-A-FF-A-NNN-*** | MPT025CS7AHNNBAAABJJDRAFFBCAABJJDRAFFANNN*** |
| M91-25211 | MPT-025-C-S-7-A-H-NN-B-A-A-A-BJJ-DR-A-FF-B-C-A-A-BJJ-DR-A-FF-D-NNN-*** | MPT025CS7AHNNBAAABJJDRAFFBCAABJJDRAFFDNNN*** |
| M91-25185 | MPT-025-C-S-L-A-E-NN-B-A-A-A-BDD-DR-A-FF-B-C-A-A-BDD-DR-A-FF-A-NNN-*** | MPT025CSLAENNBAAABDDDRAFFBCAABDDDRAFFANNN*** |
| M91-25148 | MPT-025-C-S-L-A-E-NN-B-A-A-A-BJJ-DL-A-FF-B-C-A-A-BJJ-DL-A-FF-A-NNN-*** | MPT025CSLAENNBAAABJJDLAFFBCAABJJDLAFFANNN*** |
| M91-25220 | MPT-025-C-S-L-A-G-NN-B-A-A-A-BDD-DL-A-FF-B-C-A-A-BDD-DL-A-FF-A-NNN-*** | MPT025CSLAGNNBAAABDDDLAFFBCAABDDDLAFFANNN*** |
| 83002881 | MPT-025-C-S-L-A-G-NN-B-A-A-A-BDD-DR-A-FF-B-A-A-A-BDD-DL-A-FF-A-NNN-*** | MPT025CSLAGNNBAAABDDDRAFFBAAABDDDLAFFANNN*** |
| M91-25219 | MPT-025-C-S-L-A-G-NN-B-A-A-A-BDD-DR-A-FF-B-C-A-A-BDD-DR-A-FF-A-NNN-*** | MPT025CSLAGNNBAAABDDDRAFFBCAABDDDRAFFANNN*** |
| M91-25154 | MPT-025-C-S-L-A-G-NN-B-A-A-A-BHH-DR-A-FF-B-C-A-A-BHH-DR-A-FF-A-NNN-*** | MPT025CSLAGNNBAAABHHDRAFFBCAABHHDRAFFANNN*** |
| 80002820 | MPT-025-C-S-L-A-G-NN-B-A-A-A-BJJ-DL-A-FF-B-A-A-A-BJJ-DL-A-FF-A-NNN-*** | MPT025CSLAGNNBAAABJJDLAFFBAAABJJDLAFFANNN*** |
| 83001901 | MPT-025-C-S-L-A-H-NN-B-A-A-A-BJJ-DL-A-FF-B-A-A-A-BJJ-DL-A-FF-A-NNN-*** | MPT025CSLAHNNBAAABJJDLAFFBAAABJJDLAFFANNN*** |
| M91-25239 | MPT-025-C-S-L-A-J-NN-B-A-A-A-BBB-DL-A-FF-B-A-A-A-BBB-DL-A-FF-D-NNN-*** | MPT025CSLAJNNBAAABBBDLAFFBAAABBBDLAFFDNNN*** |
| M91-25160 | MPT-025-C-S-R-A-C-NN-B-A-A-A-BDD-DL-A-FF-B-C-A-A-BDD-DR-A-FF-A-NNN-*** | MPT025CSRACNNBAAABDDDLAFFBCAABDDDRAFFANNN*** |
| M91-25180 | MPT-025-C-S-R-A-C-NN-B-A-A-A-BFF-DR-A-FF-B-C-A-A-BFF-DR-A-FF-A-NNN-*** | MPT025CSRACNNBAAABFFDRAFFBCAABFFDRAFFANNN*** |
| M91-25182 | MPT-025-C-S-R-A-C-NN-B-A-A-A-BJJ-DR-A-FF-B-C-A-A-BJJ-DR-A-FF-A-NNN-*** | MPT025CSRACNNBAAABJJDRAFFBCAABJJDRAFFANNN*** |
| 83010024 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BBB-DR-A-FF-B-A-A-A-BBB-DL-A-FF-A-NNN-*** | MPT025CSRAENNBAAABBBDRAFFBAAABBBDLAFFANNN*** |
| M91-25129 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BBB-DR-A-FF-B-C-A-A-BBB-DR-A-FF-A-NNN-*** | MPT025CSRAENNBAAABBBDRAFFBCAABBBDRAFFANNN*** |
| M91-25155 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BBB-DR-A-FF-B-C-A-A-BBB-DR-A-FF-D-NNN-*** | MPT025CSRAENNBAAABBBDRAFFBCAABBBDRAFFDNNN*** |
| 83069321 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BCC-DL-A-FF-B-C-A-A-BCC-DL-A-FF-D-NNN-*** | MPT025CSRAENNBAAABCCDLAFFBCAABCCDLAFFDNNN*** |
| M91-25228 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BCC-DR-A-FF-B-C-A-A-BCC-DR-A-FF-D-NNN-*** | MPT025CSRAENNBAAABCCDRAFFBCAABCCDRAFFDNNN*** |
| 80002086 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BDD-DL-A-FF-B-A-A-A-BDD-DR-A-FF-A-NNN-*** | MPT025CSRAENNBAAABDDDLAFFBAAABDDDRAFFANNN*** |
| M91-25133 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BDD-DL-A-FF-B-C-A-A-BDD-DL-A-FF-A-NNN-*** | MPT025CSRAENNBAAABDDDLAFFBCAABDDDLAFFANNN*** |
| M91-25111 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BDD-DL-A-FF-B-C-A-A-BDD-DR-A-FF-A-NNN-*** | MPT025CSRAENNBAAABDDDLAFFBCAABDDDRAFFANNN*** |
| M91-25137 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BDD-DR-A-FF-B-C-A-A-BDD-DL-A-FF-A-NNN-*** | MPT025CSRAENNBAAABDDDRAFFBCAABDDDLAFFANNN*** |
| M91-25135 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BDD-DR-A-FF-B-C-A-A-BDD-DR-A-FF-A-NNN-*** | MPT025CSRAENNBAAABDDDRAFFBCAABDDDRAFFANNN*** |
| M91-25139 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BEE-DL-A-FF-B-C-A-A-BEE-DL-A-FF-A-NNN-*** | MPT025CSRAENNBAAABEEDLAFFBCAABEEDLAFFANNN*** |
| 83044597 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BEE-DL-A-FF-B-C-A-A-BEE-DR-A-FF-A-NNN-*** | MPT025CSRAENNBAAABEEDLAFFBCAABEEDRAFFANNN*** |
| 83002194 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BEE-DR-A-FF-B-A-A-A-BEE-DL-A-FF-A-NNN-*** | MPT025CSRAENNBAAABEEDRAFFBAAABEEDLAFFANNN*** |
| M91-25131 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BFF-DL-A-FF-B-C-A-A-BFF-DL-A-FF-A-NNN-*** | MPT025CSRAENNBAAABFFDLAFFBCAABFFDLAFFANNN*** |
| M91-25144 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BFF-DR-A-FF-B-C-A-A-BFF-DR-A-FF-A-NNN-*** | MPT025CSRAENNBAAABFFDRAFFBCAABFFDRAFFANNN*** |
| 83003139 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BGG-DL-A-FF-B-A-A-A-BGG-DL-A-FF-A-NNN-*** | MPT025CSRAENNBAAABGGDLAFFBAAABGGDLAFFANNN*** |
| M91-25115 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BGG-DL-A-FF-B-C-A-A-BGG-DL-A-FF-A-NNN-*** | MPT025CSRAENNBAAABGGDLAFFBCAABGGDLAFFANNN*** |
| 80005257 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BGG-DR-A-FF-B-C-A-A-BGG-DL-A-FF-A-NNN-*** | MPT025CSRAENNBAAABGGDRAFFBCAABGGDLAFFANNN*** |
| M91-25134 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BHH-DL-A-FF-B-C-A-A-BHH-DR-A-FF-A-NNN-*** | MPT025CSRAENNBAAABHHDLAFFBCAABHHDRAFFANNN*** |
| M91-25142 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BJJ-DL-A-FF-B-C-A-A-BJJ-DR-A-FF-A-NNN-*** | MPT025CSRAENNBAAABJJDLAFFBCAABJJDRAFFANNN*** |
| M91-25153 | MPT-025-C-S-R-A-E-NN-B-A-A-A-BJJ-DR-A-FF-B-C-A-A-BJJ-DR-A-FF-A-NNN-*** | MPT025CSRAENNBAAABJJDRAFFBCAABJJDRAFFANNN*** |
| M91-25138 | MPT-025-C-S-R-A-F-NN-B-A-A-A-BDD-DR-A-FF-B-C-A-A-BDD-DL-A-FF-A-NNN-*** | MPT025CSRAFNNBAAABDDDRAFFBCAABDDDLAFFANNN*** |
| M91-25141 | MPT-025-C-S-R-A-F-NN-B-A-A-A-BJJ-DL-A-FF-B-C-A-A-BJJ-DL-A-FF-A-NNN-*** | MPT025CSRAFNNBAAABJJDLAFFBCAABJJDLAFFANNN*** |
| M91-25208 | MPT-025-C-S-R-A-G-NN-B-A-A-A-BDD-DL-A-FF-B-C-A-A-BDD-DR-A-FF-A-NNN-*** | MPT025CSRAGNNBAAABDDDLAFFBCAABDDDRAFFANNN*** |
| M91-25177 | MPT-025-C-S-R-A-G-NN-B-A-A-A-BDD-DR-A-FF-B-C-A-A-BDD-DR-A-FF-A-NNN-*** | MPT025CSRAGNNBAAABDDDRAFFBCAABDDDRAFFANNN*** |
| M91-25202 | MPT-025-C-S-R-A-G-NN-B-A-A-A-BFF-DR-A-FF-B-C-A-A-BFF-DL-A-FF-A-NNN-*** | MPT025CSRAGNNBAAABFFDRAFFBCAABFFDLAFFANNN*** |
| M91-25179 | MPT-025-C-S-R-A-G-NN-B-A-A-A-BFF-DR-A-FF-B-C-A-A-BFF-DR-A-FF-A-NNN-*** | MPT025CSRAGNNBAAABFFDRAFFBCAABFFDRAFFANNN*** |
| M91-25184 | MPT-025-C-S-R-A-G-NN-B-A-A-A-BGG-DL-A-FF-B-C-A-A-BGG-DR-A-FF-A-NNN-*** | MPT025CSRAGNNBAAABGGDLAFFBCAABGGDRAFFANNN*** |
| M91-25243 | MPT-025-C-S-R-A-G-NN-B-A-A-A-BHH-DL-A-FF-B-C-A-A-BHH-DL-A-FF-A-NNN-*** | MPT025CSRAGNNBAAABHHDLAFFBCAABHHDLAFFANNN*** |
| M91-25146 | MPT-025-C-S-R-A-G-NN-B-A-A-A-BHH-DL-A-FF-B-C-A-A-BHH-DR-A-FF-A-NNN-*** | MPT025CSRAGNNBAAABHHDLAFFBCAABHHDRAFFANNN*** |
| M91-25116 | MPT-025-C-S-R-A-G-NN-B-A-A-A-BHH-DR-A-FF-B-C-A-A-BHH-DL-A-FF-A-NNN-*** | MPT025CSRAGNNBAAABHHDRAFFBCAABHHDLAFFANNN*** |
| M91-25198 | MPT-025-C-S-R-A-G-NN-B-A-A-A-BHH-DR-A-FF-B-C-A-A-BHH-DR-A-FF-A-NNN-*** | MPT025CSRAGNNBAAABHHDRAFFBCAABHHDRAFFANNN*** |
| M91-25229 | MPT-025-C-S-R-A-G-NN-B-A-A-A-BJJ-DL-A-FF-B-C-A-A-BJJ-DL-A-FF-A-NNN-*** | MPT025CSRAGNNBAAABJJDLAFFBCAABJJDLAFFANNN*** |
| 83003760 | MPT-025-C-S-R-A-G-NN-B-A-A-A-BJJ-DR-A-FF-B-A-A-A-BJJ-DL-A-FF-D-NNN-*** | MPT025CSRAGNNBAAABJJDRAFFBAAABJJDLAFFDNNN*** |
| M91-25124 | MPT-025-C-S-R-A-G-NN-B-A-A-A-BJJ-DR-A-FF-B-C-A-A-BJJ-DL-A-FF-A-NNN-*** | MPT025CSRAGNNBAAABJJDRAFFBCAABJJDLAFFANNN*** |
| M91-25162 | MPT-025-C-S-R-A-H-NN-B-A-A-A-BDD-DL-A-FF-B-C-A-A-BDD-DR-A-FF-A-NNN-*** | MPT025CSRAHNNBAAABDDDLAFFBCAABDDDRAFFANNN*** |
| M91-25200 | MPT-025-C-S-R-A-H-NN-B-A-A-A-BDD-DR-A-FF-B-C-A-A-BDD-DL-A-FF-A-NNN-*** | MPT025CSRAHNNBAAABDDDRAFFBCAABDDDLAFFANNN*** |
| 83043373 | MPT-025-C-S-R-A-H-NN-B-A-A-A-BFF-DR-A-FF-B-C-A-A-BFF-DR-A-FF-A-NNN-*** | MPT025CSRAHNNBAAABFFDRAFFBCAABFFDRAFFANNN*** |
| 83010764 | MPT-025-C-S-R-A-H-NN-B-A-A-A-BJJ-DL-A-FF-B-C-A-A-BJJ-DL-A-FF-A-NNN-*** | MPT025CSRAHNNBAAABJJDLAFFBCAABJJDLAFFANNN*** |
| M91-25196 | MPT-025-C-S-R-A-H-NN-B-A-A-A-BJJ-DR-A-FF-B-C-A-A-BJJ-DR-A-FF-A-NNN-*** | MPT025CSRAHNNBAAABJJDRAFFBCAABJJDRAFFANNN*** |
| M91-25242 | MPT-025-C-S-R-A-J-NN-B-A-A-A-BBB-DL-A-FF-B-A-A-A-BBB-DL-A-FF-A-NNN-*** | MPT025CSRAJNNBAAABBBDLAFFBAAABBBDLAFFANNN*** |
| M91-25149 | MPT-025-C-S-R-A-J-NN-B-A-A-A-BHH-DL-A-FF-B-C-A-A-BHH-DR-A-FF-A-NNN-*** | MPT025CSRAJNNBAAABHHDLAFFBCAABHHDRAFFANNN*** |
| 83029298 | MPT-025-C-S-R-A-R-NN-B-A-A-A-BFF-DR-A-FF-B-C-A-A-BFF-DR-A-FF-A-NNN-*** | MPT025CSRARNNBAAABFFDRAFFBCAABFFDRAFFANNN*** |
| M91-25126 | MPT-025-C-S-R-A-R-NN-B-A-A-A-BJJ-DL-A-FF-B-C-A-A-BBB-DR-A-FF-A-NNN-*** | MPT025CSRARNNBAAABJJDLAFFBCAABBBDRAFFANNN*** |
| M91-25215 | MPT-025-C-S-W-A-A-NN-B-A-A-A-BGG-DL-A-FF-B-C-A-A-BGG-DL-A-FF-A-NNN-*** | MPT025CSWAANNBAAABGGDLAFFBCAABGGDLAFFANNN*** |
| 83012672 | MPT-025-C-S-W-A-A-NN-B-A-A-A-BGG-DR-A-FF-B-C-A-A-BGG-DL-A-FF-A-NNN-*** | MPT025CSWAANNBAAABGGDRAFFBCAABGGDLAFFANNN*** |
| M91-25238 | MPT-025-C-S-W-A-C-NN-B-A-A-A-BFF-DL-A-FF-B-C-A-A-BFF-DL-A-FF-A-NNN-*** | MPT025CSWACNNBAAABFFDLAFFBCAABFFDLAFFANNN*** |
| M91-25212 | MPT-025-C-S-W-A-E-NN-B-A-A-A-BDD-DR-A-FF-B-C-A-A-BDD-DR-A-FF-A-NNN-*** | MPT025CSWAENNBAAABDDDRAFFBCAABDDDRAFFANNN*** |
| M91-25191 | MPT-025-C-S-W-A-E-NN-B-A-A-A-BGG-DL-A-FF-B-C-A-A-BGG-DL-A-FF-A-NNN-*** | MPT025CSWAENNBAAABGGDLAFFBCAABGGDLAFFANNN*** |
| M91-25237 | MPT-025-C-S-W-A-E-NN-B-A-A-A-BGG-DR-A-FF-B-C-A-A-BGG-DR-A-FF-A-NNN-*** | MPT025CSWAENNBAAABGGDRAFFBCAABGGDRAFFANNN*** |
| M91-25231 | MPT-025-C-S-W-A-E-NN-B-A-A-A-BJJ-DR-A-FF-B-C-A-A-BJJ-DR-A-FF-A-NNN-*** | MPT025CSWAENNBAAABJJDRAFFBCAABJJDRAFFANNN*** |
| M91-25225 | MPT-025-C-S-W-A-G-NN-B-A-A-A-BDD-DL-A-FF-B-C-A-A-BDD-DL-A-FF-A-NNN-*** | MPT025CSWAGNNBAAABDDDLAFFBCAABDDDLAFFANNN*** |
| 83010061 | MPT-025-C-S-W-A-G-NN-B-A-A-A-BGG-DL-A-FF-B-C-A-A-BGG-DL-A-FF-A-NNN-*** | MPT025CSWAGNNBAAABGGDLAFFBCAABGGDLAFFANNN*** |
| M91-25236 | MPT-025-C-S-W-A-G-NN-B-A-A-A-BHH-DR-A-FF-B-C-A-A-BFF-DL-A-FF-A-NNN-*** | MPT025CSWAGNNBAAABHHDRAFFBCAABFFDLAFFANNN*** |
| M91-25235 | MPT-025-C-S-W-A-G-NN-B-A-A-A-BHH-DR-A-FF-B-C-A-A-BHH-DL-A-FF-A-NNN-*** | MPT025CSWAGNNBAAABHHDRAFFBCAABHHDLAFFANNN*** |
| M91-25204 | MPT-025-C-S-W-A-G-NN-B-A-A-A-BHH-DR-A-FF-B-C-A-A-BHH-DR-A-FF-A-NNN-*** | MPT025CSWAGNNBAAABHHDRAFFBCAABHHDRAFFANNN*** |
| M91-25234 | MPT-025-C-S-W-A-J-NN-B-A-A-A-BBB-DR-A-FF-B-C-A-A-BBB-DR-A-FF-A-NNN-*** | MPT025CSWAJNNBAAABBBDRAFFBCAABBBDRAFFANNN*** |
| M91-25227 | MPT-025-C-S-Y-A-G-NN-B-A-A-A-BDD-DL-A-FF-B-C-A-A-BDD-DL-A-FF-A-NNN-*** | MPT025CSYAGNNBAAABDDDLAFFBCAABDDDLAFFANNN*** |
Q1:What is the core design feature of the MPT025 hydraulic pump?
A1:The core design feature of the MPT025 hydraulic pump is its tandem configuration, which integrates two variable-displacement axial piston pump units onto a single drive shaft within one compact housing.
Q2:What is a key advantage of the MPT025's tandem design?
A2:A key advantage of the MPT025 hydraulic pump's tandem design is its ability to supply two independent hydraulic circuits from a single power source, saving space and simplifying system layout compared to using two separate pumps.
Q3:How to purchase a MPT025 hydraulic pump?
A3:You can click on the right sidebar or the contact information in the top bar to contact us to purchase. You can do so via email, form, WeChat, WhatsApp, or other methods.
Q4:What is the price and delivery time of the MPT025 hydraulic pump?
A4:The specific price and delivery time will be provided based on the specific model you provide.
